Custom CNC Machining Lens Parts

With 15 years of experience, we produce high-quality cnc machined optical lens parts for various metal structures. Our CNC workshop focuses on delivering the exact dimensions and durable metal bodies needed to protect and support sensitive imaging systems.

Start Your Instant Quote

Our Partners

partners bell partners axa Tesla partners cubic partners testeo partners vtech partners hms partners vishay

Custom CNC Lens Parts Manufactured by VMT

VMT has collaborated with more than 150 specialized optical instrumentation companies to transform their sophisticated metal designs into reality. To date, our facility has supplied over 50,000 optical instrument parts, featuring 6,000+ units of cnc machined optical lens parts engineered for stable performance in high-end imaging systems.
With 15 years of experience, we have processed these cnc machined optical lens parts for multiple brands, focusing on unique customer specifications. Our project history includes the custom production of camera lens parts, laser lens spare parts, and microscope parts objective lens. Additionally, we have fulfilled custom orders for dslr lens parts, internal parts of a camera lens, microscope lens parts, and objective lens parts based on provided technical drawings.

Lens Barrel

Get a Quick Quote

Lens Retaining Ring

Get a Quick Quote

Lens Spacer Ring

Get a Quick Quote

Lens Focusing Ring

Get a Quick Quote

Lens Helicoid Sleeve

Get a Quick Quote

Lens Mount Adapter

Get a Quick Quote

Lens Mounting Flange

Get a Quick Quote

Lens Baffle Ring

Get a Quick Quote

Lens Filter Thread Ring

Get a Quick Quote

CNC Machining Lens Parts Manufacturing Services

VMT supports every stage from rapid prototyping to mass production. We ensure technical precision for all optical mount components, providing a seamless transition for complex manufacturing requirements.

CNC Turning

We utilize precision turning to produce cylindrical lens housings with absolute concentricity. By machining internal shoulders and mounting threads in a single setup, we ensure the rigid, center-aligned seating necessary for stable optical alignment.

Get a Quick Quote

Rapid CNC prototyping and manufacturing services

CNC Milling (3/4/5-Axis)

We utilize multi-axis milling for complex optical mounts and non-cylindrical housings. Our 5-axis capability enables the machining of intricate geometries in a single setup, eliminating cumulative errors to ensure precise alignment for multi-element lens systems.

Get a Quick Quote

Swiss Machining

We utilize Swiss-type lathes for miniature lens parts and slender adjustment screws. This process ensures micron-level concentricity and burr-free finishes for micro-optics by supporting the workpiece directly at the cutting zone.

Get a Quick Quote

Tapping And Thread Grinding

We provide precision tapping and thread grinding to ensure smooth, debris-free engagement for lens mounts and filter threads. This process delivers exact pitch accuracy and verticality, preventing cross-threading and ensuring alignment during assembly.

Get a Quick Quote

Wire Edm

We utilize wire EDM to cut intricate profiles and sharp internal corners that traditional milling cannot reach. This non-contact process prevents mechanical stress on thin-walled lens structures, ensuring micron-level accuracy for complex optical slots and apertures.

Get a Quick Quote

Precision Boring

Precision Boring We utilize precision boring to achieve micron-level diameter tolerances (±0.005mm) for critical lens seating. This process ensures the absolute roundness and surface finish required for the secure, centered placement of high-end optical elements.

Get a Quick Quote

Drilling & Reaming

We utilize precision drilling and reaming to produce smooth, high-tolerance holes for positioning pins and optical paths. This ensures the exact diameter and straightness required for accurate mechanical registration in lens assemblies.

Get a Quick Quote

Ultrasonic Cleaning

We utilize vacuum cleaning to remove microscopic oils and residual gases from parts. This ensures a contaminant-free surface, preventing outgassing and fogging within sealed optical assemblies.

Get a Quick Quote

How Does VMT Ensure Concentricity for Custom CNC Machining Lens Parts?

Single-Setup Machining: We complete the internal bore, threads, and outer diameter in one single clamping using Turn-Mill Multitasking Centers and Swiss-type Lathes. By not moving the part between steps, we eliminate the positioning errors that occur when a part is re-clamped.
Precision Boring: For lens seats, we use specialized boring bars instead of standard drilling or milling. This process corrects any hole drift from the initial roughing, achieving a roundness and concentricity tolerance of ±0.005mm.
In-Process Probing: We use Renishaw probes inside the machine to measure parts during production. The system automatically adjusts for microscopic tool wear or thermal shifts, ensuring every part in a 1,000-unit batch is identical.
Stress Relief: Thin-walled optical parts can warp after machining. We use Heat Treatment or Vibrational Aging to “relax” the metal, ensuring the part stays perfectly round even after surface finishing like anodizing.
CMM Verification: Every critical dimension is verified by a Coordinate Measuring Machine (CMM). This provides a digital report proving the concentricity between the internal lens seat and the external mount.

Start Your Instant Quote

Custom CNC Machining Lens Parts Material Selection

We utilize a range of common materials for optical mount components, selected for their specific mechanical and thermal properties. The following table outlines the material grades and their primary technical advantages:

Material	Grade / Alloy	Reason For Use
Aluminum	6061, 7075, 6063	Lightweight, high strength, excellent anodizing
Stainless Steel	303, 304, 316	Corrosion resistance, high dimensional stability
Brass & Bronze	C3604, C93200	Self-lubricating, high wear resistance
Titanium	Grade 2, Grade 5	Extreme strength-to-weight, thermal stability
Engineering Plastics	PEEK, POM, PTFE	Low friction, electrical insulation, chemical resistance
Copper	C11000, Tellurium Copper	Superior thermal and electrical conductivity
Invar & Kovar	Invar 36, Kovar	Extremely low thermal expansion

Aluminum

Stainless Steel

Brass

Titanium

Engineering Plastics

Copper

Bronze

Typical Surface Treatment of Lens Parts

Before machining optical mount components, our engineers select the optimal finishing method to address stray light and precision requirements. Common surface treatments for optical mount components include:

Qualify Evaluation Report

For each order we receive, we tailor a comprehensive suite of quality inspection reports aligned with your specific processing needs.

Inspection Report:

Full Dimensional Report:
This report details the complete dimensional measurements of the processed parts, ensuring precision and adherence to design specifications.
Material Certification & Test Report:
This document verifies the material’s compliance with specified standards and includes test results that attest to its quality, durability, and suitability for the intended application.

Certificate

As an experienced manufacturer specializing in on-demand CNC machined parts, we have the following certifications:

ISO 9001:2015
IATF 16949:2015
ROHS Directive
12 patent certifications

FAQ about Custom CNC Machining Lens Parts

What are the parts of the lens?

A complete lens assembly includes the Optical Elements (glass), Lens Barrel (housing), Retaining Rings (locking elements), Spacers (setting distances), and Diaphragms (controlling light). VMT specializes in machining the high-precision mechanical components that hold and protect these glass elements.

What are the six types of lenses?

Lenses are categorized by their curvature:

1.Plano-Convex

2. Double Convex

3. Concavo-Convex (Meniscus)

4. Plano-Concave

5. Double Concave

6. Convexo-Concave.

We provide custom mounts and housings tailored to the specific geometry of each type.

Does VMT provide full sub-assembly services?

Yes. We offer sub-assembly for lens barrels and optical mounts, including the installation of spacers, pins, and hardware. We deliver ready-to-use mechanical structures, reducing your assembly workload and ensuring perfect mechanical registration between all CNC-machined components.

Does VMT provide DFM support for complex optical designs?

Absolutely. Our engineers provide DFM analysis to optimize your designs for concentricity and thread precision. This support helps reduce costs and ensures your complex optical parts are optimized for stable, high-quality mass production.

What is your typical lead time for optical prototyping vs. mass production?

For prototypes, our lead time is typically 3–7 days. For mass production, it ranges from 2–4 weeks depending on complexity and finishing. We offer flexible scheduling to meet tight project deadlines without compromising on micron-level precision.

Do you offer material certification and full traceability?

Yes. We provide full material mill certifications and RoHS/REACH compliance reports. Every project includes complete traceability, from raw material sourcing to final CMM inspection, ensuring all components meet strict international quality and safety standards.
